Product specifications
Evaluation Kit for Power Amplifiers PA01, PA10, PA12, PA51, PA61, PA73 and PA119.
** This EK does NOT contain the actual amplifier device, so that needs to be ordered separately **
This easy to use kit provides a platform with good circuit board layout and grounding to evaluate above Power Amplifiers.
With additional prototype area, it is flexible enough to analyze a multitude of standard or proprietary circuit configurations.
Similar circuitry is used for evaluation and the circuit for a particular package can be changed using jumpers. External connections to the evaluation kit can be made through the connectors at the edges of the circuit. The circuit provides a line termination of 50O.
All the Power amplifiers are configured for a gain of 21. This evaluation kit provides flexibility for modifying the gain, in inverting or non-inverting mode and for using a differential amplifier configuration.
- APEX Microtechnology product -
