Product specifications
HS09 - TO-3 Heatsink
Type ............................................ Board Level
Package Cooled ............................... PDIP
Attachment Method .......................... Bolt On
Shape .......................................... Rhombus
Length ......................................... 1.630" (41.40mm)
Width .......................................... 1.290" (32.77mm
Diameter ....................................... -
Height Off Base (Height of Fin) ............ 0.750" (19.05mm)
Power Dissipation @ Temperature Rise ... 7W @ 80°C
Thermal Resistance @ Forced Air Flow .... 14.0°C/W @ 200 LFM
Thermal Resistance @ Natural .............. 11.7°C/W
Material ........................................ Aluminum
Material Finish .................................. Black Anodized
- APEX Microtechnology product -
